Lil Programming Questions Sticky

A topic by Internet Janitor created Oct 28, 2022 Views: 3,990 Replies: 152
Viewing posts 1 to 20 of 48 · Next page · Last page
Developer(+1)

This thread is for small questions about Lil, the Decker scripting language. If you have a more involved question, feel free to start your own thread. If we accumulate enough information for an FAQ I'll edit this post to include a link.

The Lil manual can be found here.

(+1)

Lil performance question: I have used LiveCode for years, and its built-in language is not fast. So when I try out a new language, the first thing I do after Hello World is a for loop to get a sense of the speed of the language. I tried that with Lil on an M1 MacBook, and found that

on click do
each x in range 1000000
end
 alert["Done!"]
end

takes about 2 seconds to run. This is about 30x slower than even LiveCode. This is not a criticism, just a question: any thoughts on ways to speed up Lil?

Developer (4 edits) (+1)

There's a lot of room for improvement in Lil performance. The each loop in your example is particularly expensive because "each" is a map operation yielding a result list, range eagerly creates an entire list, and each loop body is executed in its own scope. Contrast with "while", which is considerably faster due to involving less bookkeeping and keeping much less in memory at once:

while x<1000000
  x:1+x
end

Or, when it's possible, just using the natural "conforming" over lists:

1+range 1000000

Performance for each over a huge list is particularly bad in c-lil; I'll do some investigating.

Interesting -- I'm not terribly familiar with list generation: I've played with Python, so I know it's a thing, but LiveCode has nothing like it built in, and I would never do something like

repeat with i = 1 to 1000000
    put i,"" after aList
end repeat
repeat for each item i in aList
    -- do something
end repeat

I just checked and found that the while loop was even slower :-)

I'm not sure this accomplishes the same task, albeit that the task is synthetic in the first place, but in any case, this is about 20x faster:

on click do
range 10000000
 alert["Done!"]
end
Developer (1 edit)

Oh, there's one other thing I should note that's probably making us talk past one another somewhat: Lil in Decker is deliberately capped at a specific number of "ops" (VM bytecode steps) per "frame" (display updates at 60fps) . This is an arbitrary creative constraint intended to help decks behave more consistently across different machines with wildly different levels of performance. The "FRAME_QUOTA" constant in the JavaScript implementation controls this cutoff.

Oh, HA! Okay, that makes sense. "constant in the JavaScript implementation" -- meaning updating it requires rebuilding Decker from source? Or is it configurable?

Developer

You can rebuild from source, or, in a web build, just open the file in your favorite text editor, search for "FRAME_QUOTA", and tweak as desired. I may raise the limit and/or make it configurable at runtime in the future.

(1 edit)

LiveCode script (and the GPLv3 community fork OpenXTalk) has arrays which can be considerably faster then using comma-seperated-values for  text container 'lists' (but when I do I use tab as a delimiter).
Also LC / OXT has a second language, the Extension Builder lang for making 'Widgets' and wrapping external code libraries, which does have an actual List type where the ordered elements can be of any type, Text, Numbers, JSON, Java, or C and ObjC types, Pointers, etc.

What's a good way to get an image string? I was trying `read["image"]` in c-lil and I was only getting the contents of the file as a byte string.

so I tried to get it from js-lil, and I couldn’t manage to copy the string out of the listener. After copying it and pasting it in the script editor, the string appears as an image within the script..

for reference, the image string is

%%IMG2ACIAGCAuAQwgEgEEIAYBAiAEAQIgEAEEIAYBAiAEAQIgDgECIAgBAiAIAQIgDAECIAgBAiAIAQIgCgECIAoBAiAGAQIgAgECIAgBAiAKAQIgBgECIAIBAiAGAQIgDAECIAYBAiACAQIgBgECIAwBAiAGAQIgAgECIAYBCiAGAQIgCAECIAYBCiAGAQIgCAECIAQBAiAKAQIgBgEMIAIBAiAKAQIgBgEMIAIBAiAKAQIgBAECIAwBBCAKAQIgBAECIAwBAiACAQogBAECIAIBDCAEAQogBAECIAIBDCAGAQIgDAECIAoBAiAGAQIgDAECIAoBAiAIAQQgCgEKIAoBBCAKAQogDgEKIBgBCiAO

and this is a screenshot of what happens:

Developer(+1)

Pasting images in non-rich fields was a bug; this should be fixed now. Image strings are how images are represented in the clipboard, so you should now be able to make image-strings using normal drawing tools.

Lilt's read[] has a slightly different signature than Decker, since Decker prompts the user instead of taking a path argument; that might be what was tripping you up there.

(+2)

What is a good way to order a query by two values? I’m making a flash-card deck and want to sort the cards based on some “score” I calculate, and if they’re equal fall back on the time they were last accessed. Tupling the values is not an option, since anything but an integer will be converted to string for comparison. I could just do that with nested queries, but that doesn’t feel very good.

Developer(+1)

Well, you could've formatted columns together to form keys with a natural lexicographic comparison, but that's horrible.

I made a tweak to the behavior of "orderby" which borrows from how the "grade" operators work in K: lists are now given a lexicographic comparison, so tupling will now work. The "join" operator will zip together columns for this purpose. As a contrived example:

    e:insert c:""split"ABBBABABABABAAABA" n:(7,7,2,4,4,0,3,4,2,0,9,7,4,6,8,2,3) into 0
    select c n orderby (c join n) asc from e
+-----+---+
| c   | n |
+-----+---+
| "A" | 2 |
| "A" | 3 |
| "A" | 3 |
| "A" | 4 |
| "A" | 4 |
| "A" | 6 |
| "A" | 7 |
| "A" | 8 |
| "A" | 9 |
| "B" | 0 |
| "B" | 0 |
| "B" | 2 |
| "B" | 2 |
| "B" | 4 |
| "B" | 4 |
| "B" | 7 |
| "B" | 7 |
+-----+---+
(+4)

Would be cool if Decker had a discord server, or a channel on the Fantasy Consoles server

(+2)

You could ask in the Fantasy Consoles server to add a channel?

(+1)

Is there a good way of returning multiple values from a function? For now the best I have is to pack them in a list and manually unpack to variables. Something like Lua’s unpacking would be really handy, but it conflicts with the current syntax: a, b: 1, 2 is a list of a, 1, 2 and assignment of 1 to b. In a world of pure functions it’s really hard to avoid multiple output.

(4 edits) (+2)

Not really an answer to my question, but a solution to my problem: I found a way to store mutable state. Using closures it’s possible to write “constructors” that return “objects” which have persistent mutable state, and calling “methods” of the “object” will change its state for all references to the object. Here’s an example of a stack constructor I’m using in my current project:

on new_stack do
 state: ()
 ("stack","push","peek","pop") dict
 (on _ do state end
 ,on _ x do state[count state]: x end
 ,on _ do (-1 take state)[0] end
 ,on _ do ans:-1 take state state:-1 drop state ans[0] end
 )
end

This method is used in the example module in the documentation, although outside the function so it only creates a single global mutable state.

Edit: A universal minimal mutable variable:

on new_var state do
 ("get","set") dict
 (on _ do state end
 ,on _ new do state:new end
 )
end
(+1)

my question is kinda rudimentary in nature, so how do I make a sound play continuously in a card? I want it to be played after the button click sound ends(we arrive at card) and play until another button is interacted with, thanks in advance!

Developer

Waiting for all sounds to finish is straightforward: sleep["play"]

So, playing a sound during a transition, letting the sound finish, and then playing another might have a script like:

play["firstSound"]
go[anotherCard "BoxIn"]
sleep["play"]
play["secondSound"]

Decker isn't really designed with looped audio in mind. Keep in mind that individual sounds in Decker are capped at 10 seconds, so they wouldn't work especially well for background music. You might be able to get continuous background noise by monitoring sys.ms and periodically issuing another play[], but it isn't straightforward. Perhaps a feature for the future...

(+1)

as someone who procrastinates a lot, i'm building a timer in decker using a field and a button to both act as a focus tool and also to apply some newfound programming knowledge. i have the basic countdown, but i'm wondering how i can make the program delay a second before going through the while loop again. any help is appreciated!

on click do
    while display.text>0
        display.text: display.text - 1
        #delay goes here
    end
end
Developer(+1)

You could use the sleep[] function to wait a given number of frames. "sleep[60]" would delay for approximately one second.

A different approach for timing (which could be more accurate over longer time periods) would be to use `sys.now` or `sys.ms` to record a starting time and then consult them periodically to determine how much time has passed, possibly using "sleep[]" to delay between checks. (See: the System interface)

(+1)

Thank you to the both of you! This helps a lot.

(3 edits) (+2)

sleep[] looks a bit unsatisfying, as the card is not interactive as it waits, so the label isn’t that readable.

I have tried this:

Make a textfield to store a timer (here I used “timer”) initially set to 0. You can put it on another card if you want to hide it out the way.

Card:

on view do
 timer.text:timer.text+1
 if (timer.text<0) & ((10%timer.text)=0)
   display.text:display.text - 1
 end
 go[card]
end

Button:

on click do
 timer.text:(display.text+1)*-10
end

Edit: I was late to the party. Using sys.now as suggested above sounds like a more suitable approach :)

Developer

Using the same "view[] refreshing" strategy is definitely the best way to do something like this if you want to be able to interact with the rest of the card while the timer is running.

You can also make the "secret timer" field invisible if you want to hide it on the current card.

https://cptnqusr.itch.io/super-cool-timer

here's the finished timer! not exactly the greatest thing ever but as a first project i'm quite happy with it

i know that lil has fuse, but how would i do something like `{x,"\n",y}/("hello";"world";"etc")` in k? i have a list of strings of arbitrary length and i want to combine them all into a single string by a delimiter. is there a way to do that?

(+1)

nevermind, i figured it out! somehow i missed that part of the lil docs.

Developer (1 edit)

To use K terminology, fuse is a dyad which takes a delimiter as its left argument:

 "\n" fuse ("hello","world","etc")
"hello\nworld\netc"
  ":ANYTHING:" fuse ("hello","world","etc")
"hello:ANYTHING:world:ANYTHING:etc"

And you can handle even fancier cases with a recursive "format":

  (list "ITEM<%s>") format ("hello","world","etc")
("ITEM<hello>","ITEM<world>","ITEM<etc>")
  ("\n","ITEM<%s>") format ("hello","world","etc")
"ITEM<hello>\nITEM<world>\nITEM<etc>"
(+2)

I may be missing something obvious, but how do you actually make a hyperlink in a field? The guided tour doesn't seem to have a script loaded into the field and the documentation doesn't specifically mention inline hyperlinks unless I missed it.

Developer(+2)

To make a hyperlink in a field, ensure that it is a "Rich Text" field (the default for new fields), switch to the Interact tool, and select a region of text within the field. You can then use the "Text -> Link..." menu item to create a hyperlink, which will be shown with a dotted underline. When you're finished editing, to make the hyperlinks "clickable" you must lock the field, by switching to the Widget tool, selecting the field, and choosing the "Widgets -> Locked" menu item.

Fields emit a "link" event when a hyperlink is clicked, which you can intercept with a script to do as you please. If you don't write a script, the default behavior is to go[] to the text you provided when you created the hyperlink. If that's the name of a card, it will navigate to that card. If it's a url like "http://google.com" it will ask the web browser to open a new tab.

Hope that helps clear things up!

(+2)

Ah, gotcha! Thank you so much!

Why does distinct not always return a list?

In the example for distinct elements given:

extract first value by value from "ABBAAC"

when all items are equal, this provides a single element instead of a single element list. I don’t know why, but in my head it seems more flexible to return a single element list.

This is what i ended up using instead, since select always returns a list. There is another workaround here since selecting the first element of each group in () will give (0), the default value, but at least that makes sense.

on uniq x do
  if x~() () else
    t:select list first value by value from x
    t.c0
  end
end
Developer (2 edits) (+1)

I think the simplest way to get the edge cases you want would be using "()," to coerce lists or scalars to lists, and using "() unless" to coerce an empty result with "first" to an empty list.

  (),extract () unless first value by value from "ABBBCD"
("A","B","C","D")
  (),extract () unless first value by value from "AAAA"
("A")
  (),extract () unless first value by value from ""
()

The former coercion is always valid, but the latter does require some care depending on the data; this is the nasty side of unifying nullity and a numeric value:

  (),extract () unless first value by value from 1,1,0,5,1,2,0,1
(1,5,2)

Edit: and another approach entirely would be to use "dict":

  range (11,22,33,0,11,22) dict ()
(11,22,33,0)
  range (11,11) dict ()
(11)
  range (0) dict ()
(0)
  range () dict ()
()

Depending upon the context, you might not even need the "range".

seems like dict is the most foolproof method. unless has the problem of ignoring zeroes.

  (),extract () unless first value by value from 0,0,0
()
Developer

Among other things, Decker 1.32 revises the behavior of extract to remove its problematic "automatic de-listing".

extract first value by value from ()

Now returns (), like it ought to have from the beginning.

Is there a better way to get the characters of a string other than this?

each x in "str" x end
Developer(+2)

I would probably use "split" with an empty string as the left argument:

  "" split "str"
("s","t","r")
(+1)

How to display an image after a delay such as sys.ms? i understand display.text but dont know how to approach image displaying, thanks for the help in advance guys!

(+2)

If you have a canvas containing the image, you can change visibility using the show attribute:

canvas_name.show: "none"
canvas_name.show: "solid"

To show or hide it on a delay, there is a simple way and a more complex way.

The simple way uses the sleep function. It (mostly) pauses the whole program until it’s finished sleeping. For example, you could use it in a button’s click action:

# Simple, e.g. button script
on click do
  card.widgets.canvas_name.show: "none"
  sleep[60] # number of frames to sleep for
  card.widgets.canvas_name.show: "solid"
end

Complex uses sys.ms and recursive go[] functions to allow other things to occur in the meanwhile. You’d need a hidden field to store some extra data. Here the image shows after 1s.

# Complex, with a field called hidden_time
# Button script
on click do
  card.widgets.canvas_name.show: "none"
  card.widgets.hidden_time.text: sys.ms
  go[card]
end
# Card script
on view do
  elapsed: sys.ms - card.widgets.hidden_time.text
  if elapsed > 1000
    card.widgets.canvas_name.show: "solid"
  else
    go[card]
  end
end
(+2)

thank you so much sunil! this was very informative, i tried the sleep method.. but i goofed it lol, this explained it very well, thank you

(2 edits) (+1)

Edit: solved!

Is there a way to include multiple where conditions?

Example:

data: select num:("1","2","3","4","5") parity:("odd","even","odd","even","odd") prime:(0,1,1,0,1) from 0

What I want:

extract num where parity="even" and prime from data

Edit: Of course I find it as soon as I post. The answer is brackets!

extract num where (parity="even") & prime from data

how does one find the upper and lower bounds of numbers in Lil?

(+1)

are there any plans to add the ability to plot a pixel in code? maybe it exists, and i haven't found it. but i think it'd be cool.

Developer

Plotting (or reading out) individual pixels on a Canvas (or an Image interface) is possible; just index or assign through them with an (x,y) pair as if they were a list or dictionary.

Plotting a large number of pixels will be fairly slow, since doing so will force the Lil interpreter to do a large number of serial operations. Both canvases and images provide a variety of higher-level methods for scaling, transforming, and drawing which operate upon pixels in bulk, and should generally be preferred, especially if the goal is any sort of realtime animation.

(+1)

thanks for the advice! really loving your work here.

(+1)

I couldn't find it in the manual, is there a way to hide the menubar?


PS I discovered this a few days ago, so awesome! Loved hypercard, and I'll join the decker jam :)

Developer (3 edits) (+1)

You can hide Decker's menu bar by "locking" a deck. In the main menu, choose "File -> Properties..". and then click "Protect..." to save a locked copy of the current deck.

In the deck file itself, this adds a line like:

locked:1

You can also manipulate whether a deck is locked on the fly by setting "deck.locked" in a script:

on click do
 deck.locked:!deck.locked
end

(Careful, though; if you use scripts to lock a deck you haven't saved yet you might get yourself stuck!)

Edit: oh, and if you meant hide the menu bar while editing, pressing "m" on your keyboard while using drawing tools will temporarily toggle the visibility of the main menu, allowing you to draw "underneath" it.

(+1)

Thanks a lot! Ow yes that second one is convenient too :)

Lilt’s write[x y] says it will write a value to a file, can it deal with image and audio interfaces? Can lil inside decker export data to a well known image/audio format?

Developer

The "write[]" functions in both Decker and Lilt can save image interfaces as .GIF images (including transparency and animation, if desired), and it can save sound interfaces as 8khz monophonic .WAV files.

The GIF files emitted by Lilt/Decker tend to be quite large, as they make no effort to compress their image data, so it may be desirable to use ImageMagick, Gifsicle, or a similar GIF optimizer to process their output.

It's also possible to write out arbitrary binary files by using an Array interface, but this is more involved.

(+2)

So excited to be working with Decker! I couldn’t find it listed elsewhere, is there a way to control the default volume a sound, or multiple sounds play at in a deck?

Developer (1 edit) (+1)

There isn't currently any kind of volume control; volumes are effectively "baked into" the amplitude of a sound's samples.

A slightly clumsy workaround would be to make a copy of an existing sound on the fly and use sound.map[] to rescale its samples. Assuming the deck contains a sound clip named "sosumi":

on play_scaled name vol do
  r:-128+range 256
  play[sound[deck.sounds[name].encoded].map[r dict floor vol*r]]
end
on click do
  play_scaled["sosumi"   1] # normal  volume
  sleep["play"]
  play_scaled["sosumi"  .5] # half    volume
  sleep["play"]
  play_scaled["sosumi" .25] # quarter volume
  sleep["play"]
  play_scaled["sosumi" .10] # 1/10th  volume
end
(+1)

got it, thanks so much for the quick response!

for an interactive adventure, how would you save a text input as a string variable for the player character's name ? i understand that it would start with a field.. say the variable for the string is playerName, and the field itself is called inputPlayerName.. would it just be the following in the script for the field?

playerName: ""

playerName: inputPlayerName.text

?? i can't test it because i also don't know how to print a string variable in a field.. simple things but still getting to grips!

Developer

In Decker, persistent state lives in widgets. If you want to remember anything beyond the scope of an event handler, it should be stored in a widget. For example:

Type of Data to StoreAppropriate Representations
StringField text
Ranged NumberSlider value
Arbitrary NumberField text
Boolean (true or false)Button value, any Widget's visibility
ImageCanvas, Rich Text Field (encoded as inline image)
TableGrid value, Field text (encoded as CSV)
Dictionary or ListField text (encoded as JSON)
Position or Sizeany Widget's bounding box

If you want to remember something without showing it to a user, you could use invisible widgets, or widgets on a hidden card.

The walkthrough and examples in this thread might be helpful to you.

I recommend checking out The Listener as a way of interactively trying short snippets of code. You can use the Listener to poke and prod at the contents of a deck or card and verify behaviors before you write a script.

The print[] and show[] Built-In Functions can be used to log information (formatted text or arbitrary Lil values, respectively) to the Listener for debugging. The alert[] function can sometimes be handy for debugging because it pauses the current script and displays text to the user. The panic[] function stops scripts completely, but can likewise be a tool for peering into the workings of complex scripts.

Does any of that help?

(+1)

yes that is really helpful! thank you for the functions and guidance about the listener- i'll keep tinkering with it! and thank you for making decker- super cool project, and it's really nice how you always answer questions

(+1)

hello- i'm so sorry to do this, but i've just spent the last 4 hours trying to figure out how to put a string variable in a field (i.e. player types in their character's name -> that name appears in text when the game or NPCs address the player's character) and i just can't? figure it out?? thank you so much for your response, i did manage to grok that you can just use the field itself as the variable (using the listener to figure that out!!) but actually taking that text and putting it in a sentence in a field is just beyond me.. i've read the reference manuals, looked at examples, gone thru the community threads and have now decided to swallow my pride and ask how you would 'embed' a string variable in a different field? like "hi [playerName], it's nice to meet you" or something like that?

sorry, i am very aware that i've been asking a lot of questions.. this is the most ambitious thing i want to do, so i don't imagine i'll be asking too many more!

Developer

No worries. Asking "obvious" questions in a public forum like this helps future users and lets me know about potential documentation/usability problems so I can continue to improve Decker.

There are a few different ways we could approach using the value of one field to update another. For starters, let's take a look at string formatting.

The Lil "format" operator takes a formatting string on the left and one or more parameters on the right. Let's see a few examples in the listener:

"Hello, %s. How's it hanging?" format "Alice"
"Hello, Alice. How's it hanging?"
"%s missed your call; they were busy %s." format ("Phil","gardening")
"Phil missed your call; they were busy gardening."

Each "%s" in the formatting string is replaced with a string on the right, in order of appearance. There are lots of other formatting codes and features available for dealing with numbers, zero-padding, case conversion, etc, but for the moment we can ignore them.

Now, let's say we have two fields on the same card: "name" and "reply":

There are a few ways we could approach updating "reply" when "name" is changed. One way would be to add a script to "name" and use the "on change" event:

on change do
 reply.text:"Hi, %s. I hope this example makes sense!" format name.text
end

It would also be possible to do the same thing when a button is clicked, etc. If "reply" was on another card, we might have to specify the "path" to it:

on change do
 otherCard.widgets.reply.text:"Hi, %s- how's it going?" format name.text
end

Both of these approaches are "push"-based: something explicitly happens to the name field and our script reaches out to other fields in response. A different way to think about it would be "pull"-based: logic on individual cards which reach out to other widgets and update themselves. For example, we could have an "on view" script on our "other card" which updates reply whenever a user travels to that card:

on view do
 reply.text:"Hi, %s- how's it going?" format firstCard.widgets.name.text
end

Either way works.

Does that get you "unstuck"?

(+1)

this is incredibly helpful! it did get me unstuck- thank you so much, i really appreciate it !!

Viewing posts 1 to 20 of 48 · Next page · Last page
