how do i make a d flip flop

A topic by lululeteugdu74 created 34 days ago Views: 163 Replies: 1
Viewing posts 1 to 2

.

The one in the video is the way i like it, it doesn't requirer a pulse. Have 2 d-latches, the data input for the second one is the output of the first one, the data input of the first one is the data input pin, the store for the second d-latch is the store input pin, and the first store is the opposite of the store input pin, by plugging it in a not
